Suspension Secrets Adjustable Rear Drop Links / End Links - BMW F22 M235I / M240I
Tax included. Shipping calculated at checkout
Suspension Secrets Adjustable Rear Drop Links / End Links – BMW F22 M235i / M240i
Restore rear anti-roll bar geometry and improve suspension balance with Suspension Secrets Adjustable Rear Drop Links for the BMW F22 M235i and M240i.
When the F22 is lowered on springs or coilovers, the position of the rear anti-roll bar can change because the factory fixed-length drop links are no longer operating at the original ride height.
This can introduce unwanted anti-roll bar preload and affect the way the rear suspension behaves from one side of the car to the other.
Suspension Secrets Adjustable Rear Drop Links allow the effective link length to be altered, helping return the anti-roll bar to a more suitable operating position and improving suspension consistency.
Why Upgrade to Adjustable Rear Drop Links?
Adjustable drop links are a useful supporting upgrade for lowered and performance-focused cars.
Potential benefits include:
- Corrected rear anti-roll bar position
- Reduced unwanted anti-roll bar preload
- More consistent rear suspension behaviour
- Improved left-to-right handling balance
- Easier corner-weighting setup
- Quick adjustment from within the wheel arch
- Suitable for road and track applications
Key Features
- Designed for BMW F22 M235i and M240i
- Fully adjustable rear drop links
- In-body adjuster nuts
- Adjustment accessible from within the wheel arch
- Billet aircraft-grade 6082 T6 aluminium bodies
- Corrosion-resistant stainless steel componentry
- Rose-jointed construction
- Motorsport-spec Fluro bearings
- Designed and manufactured in the UK
- Ideal for lowered vehicles
- Particularly useful for corner weighting
Correct Anti-Roll Bar Geometry After Lowering
Lowering the vehicle changes the relationship between the suspension and anti-roll bar.
With the standard fixed-length drop links retained, the anti-roll bar can be pulled away from its intended resting position.
Adjustable drop links allow the connection length to be altered to suit the new ride height.
This helps the anti-roll bar operate in a more appropriate position within the suspension system.
Reduce Anti-Roll Bar Preload
If the rear anti-roll bar is held under tension while the car is stationary on level ground, it can influence how the suspension behaves before the vehicle even enters a corner.
Correctly adjusted drop links help remove this unwanted preload.
Potential benefits include:
- More balanced handling
- More consistent suspension response
- Improved left-to-right behaviour
- Greater chassis predictability
Improved Left-to-Right Balance
Uneven anti-roll bar preload can make the car feel different when turning left compared with turning right.
Correctly configured adjustable links help create a more neutral suspension platform and allow the rear anti-roll bar to respond more consistently in both directions.
Ideal for Lowering Springs & Coilovers
These rear drop links are particularly useful on F22 models fitted with:
- Lowering springs
- Height-adjustable spring kits
- Coilovers
- Uprated anti-roll bars
- Performance suspension setups
The greater the change in ride height, the more worthwhile it becomes to check anti-roll bar positioning.
Quick In-Situ Adjustment
A key feature of the Suspension Secrets design is the adjuster nuts incorporated into the drop link bodies.
This allows setup changes to be made from within the wheel arch without needing to fully remove the links.
This is especially useful for:
- Trackside setup
- Workshop adjustment
- Ride-height changes
- Corner weighting
Ideal for Corner Weighting
Corner weighting can result in very small ride-height differences between individual corners of the vehicle.
If fixed-length drop links are retained, these differences can place uneven tension into the anti-roll bars.
Adjustable drop links allow the bar to be neutralised once the final ride heights have been set.
This helps prevent anti-roll bar preload from interfering with the corner-weighting process.
6082 T6 Aluminium Construction
The drop link bodies are manufactured from billet aircraft-grade 6082 T6 aluminium.
This provides a combination of:
- High strength
- Low weight
- Durability
- Performance-focused construction
Stainless Steel Componentry
The rose joints, adjusters and locking hardware use corrosion-resistant stainless steel componentry.
This helps improve durability in an area exposed to:
- Water
- Road dirt
- Salt
- Heat cycles
Motorsport-Spec Fluro Bearings
Suspension Secrets uses motorsport-spec Fluro bearings within the links to provide precise articulation and durability under demanding suspension loads.
Road & Track Applications
The adjustable rear drop links are suitable for:
- Lowered road cars
- Fast-road builds
- Clubsport setups
- Trackday cars
- Corner-weighted vehicles
Works Well With Other Suspension Upgrades
These links work particularly well alongside:
- Coilovers
- Lowering springs
- Uprated anti-roll bars
- Adjustable rear arms
- Performance geometry setups
- Corner weighting
They allow the anti-roll bar system to be configured around the rest of the suspension rather than leaving the original fixed-length links as a limitation.
Professional Setup Recommended
Although the links are designed for straightforward adjustment, the final length should be set correctly for the vehicle's ride height and suspension configuration.
For performance applications, setup by an experienced suspension or geometry specialist is recommended.
Vehicle Fitment
BMW 2 Series F22
Compatible models:
- BMW M235i F22
- BMW M240i F22
What's Included?
Each kit includes:
- 1 pair Suspension Secrets Adjustable Rear Drop Links / End Links
